Frequently Asked Questions
What materials are used in the KL75 piston seal?
The KL75 seal is constructed using a high-performance carbon-filled PTFE sealing element paired with an NBR o-ring for energized sealing.
What is the maximum operating pressure for these seals?
These PTFE piston seals are designed to handle a maximum pressure of up to 16 Bar.
Are these seals suitable for high-speed applications?
Yes, they are specifically engineered for high-speed pneumatic cylinders, reaching sliding speeds up to 4.0 M/s.
What temperature range can the KL75 seal withstand?
The seal operates effectively within a temperature range of -30°C to +105°C.
Do these seals require lubrication?
The KL75 seal is designed to operate efficiently even in dry air conditions due to the low-friction properties of the carbon-filled PTFE.
Which industry standards are these seals compatible with?
They are highly recommended for use in pneumatic cylinders manufactured according to ISO and CETOP standards.
