KL09 Heavy Duty Rod Seal Set / High Pressure Rod Seal Hydraulic

KL09 Heavy Duty Hydraulic Rod Seal Set In High Extrusion Resistance At High Pressures And Excellent Sealing PerformanceKL09 heavy duty hydraulic rod seal set consists of one elastomer sealing ring, one elastomer or fabric elastomer extrusion ring and one thermoplastic backup ring. The back-up ring and exturision ring supply long term service life while the elastomer ring gives an ability of superior sealing at variable and high pressures.

Send Inquiry

Product Description

📋
Product Specifications
Style High Pressure Rod Seal Hydraulic
Temperature (max) °C -30/+100
Pressure (max) Bar 700
Material NBR / FABRIC NBR / TPE / POM
Sliding Speed (max) M/s 0.5
Application Loading Platforms / Mining Industry
🚢
Payment & Shipping Terms
Packaging Details Opp bag
Delivery Time 7-15 work days
Payment Terms L/C, T/T, Paypal
Supply Ability 100,000 pcs /months
Heavy Duty Rod Seal Set (2)
Heavy Duty Rod Seal Set (4)
Heavy Duty Rod Seal Set (1)
⭐
Key Advantages
✔ Excellent sealing performance at variable pressures
✔ Effective sealing during vibration, sudden and shock loading
✔ High extrusion resistance at high pressures
🏗️
Area of Application
Heavy Duty Rod Seal Set (3)
🔹 Construction machinery
🔹 Loading platforms
🔹 Cranes
🔹 Heavy duty cylinders
🔹 Mining industry
📏
Technical Parameters
Model d (f8) D (H10) L (+0.4/-0) D1 (+0.1/-0) C MATERIAL
KL09-03030432030.45NBR
KL09-032324722.532.45NBR
KL09-035354722.535.45NBR
KL09-040405522.540.45NBR
KL09-045456022.545.45NBR
KL09-050506522.550.45NBR
KL09-050/1506524.550.45NBR
KL09-055557022.555.45NBR
KL09-060607522.560.45NBR
KL09-06363833763.45NBR
KL09-070708522.570.45NBR
KL09-070/170903070.45NBR
KL09-080801003080.45NBR
KL09-080/1809522.580.45NBR
KL09-085859522.585.45NBR
KL09-090901103090.45NBR
KL09-10010012030100.47NBR
KL09-11011013032.5110.47NBR
KL09-11511513030115.77NBR
KL09-115/111512522.5115.77NBR
KL09-12012014030120.77NBR
KL09-12512514529.6125.77NBR
KL09-14014015522.5140.77NBR
KL09-140/114016030140.77NBR
KL09-140/214016028140.77NBR
KL09-16016018028160.77NBR
KL09-18018020535180.77NBR
KL09-20020022535200.77NBR
KL09-22022024022.5220.710NBR
KL09-220/122024535220.710NBR
KL09-26026028030260.710NBR
KL09-260/126028535260.710NBR
❓
Frequently Asked Questions
What is the maximum pressure this rod seal can handle?
The high-pressure rod seal is designed to withstand a maximum pressure of up to 700 Bar.
What are the primary materials used in these seals?
These seals are manufactured using a combination of NBR, Fabric NBR, TPE, and POM for optimal durability and performance.
In what temperature range can these hydraulic seals operate?
They are effective in operating temperatures ranging from -30°C to +100°C.
How does the seal perform under shock loading?
The seal provides effective sealing even during vibration, sudden pressure changes, and shock loading.
What is the standard delivery time for an order?
Typical delivery time ranges between 7 to 15 working days depending on the order volume.
Are these seals suitable for the mining industry?
Yes, these heavy-duty rod seals are specifically designed for demanding applications including mining and construction machinery.
